Labs
Room No: 1
Area:
Capacity:
Incharge: Miss. M. S. Ghule
Assistant: Mr. A. J. Solanke
Weighing balances ( mechanical and digital )
Spillway, Chute Spillway and Drop Inlet Spillway )
Augers
Cut section of centrifugal pump, submersible pump and
Double Ring Infiltrometer
Positive displacement pump (Hand Pump)
Diesel Engine with Centrifugal Pump
power tiller
Cut sections of: Tractor
Single cylinder engine
Multi cylinder engine
Gear Box
Fuel injection Pump
Models of :
Lubrication system
Cooling System
Mould board
Standard disc plough
Oneway plough
Cooling System
Different Types Of Disc Harrow
Different types of agricultural discs
Furrow openers
Knap sack sprayer
Dusters
Cultivator
Surveying instruments ,
Leveling Staff/Survey Rod: Used to measure vertical distances and elevations.
Chain: Used for measuring distances, especially in chain surveying.
Tripod: Provides a stable platform for supporting surveying instruments.
Plumb Bob: Used to establish a vertical reference point.
Compass: Used to determine directions and bearings.
Ranging Rods: Used to mark points and measure distances.
Dumpy Level: A type of level used for measuring differences in elevation.
Theodolite: Measures both horizontal and vertical angles.
